L100: Concrete Filled

Contact Us

15 + 1 =
Solve this simple math problem and enter the result. E.g. for 1+3, enter 4.

Description

Pacific Stair Corporation's 100 Series Concrete Filled Stair System is our most affordable standard stair system. These stairs are intended for use in conjunction with our Concrete Filled Landings.  The pans are built to be filled with concrete after they are installed, thus creating an attractive and long-wearing surface.

Standard Stringers

  • Plate 1/4x10
  • Plate 1/4x12
  • Plate 3/8x10
  • Plate 3/8x12
  • MC10x8.4
  • MC12x10.6
  • C12x20.7

Standard Treads

  • 12 Gauge
  • 14 Gauge

Standard Finishes

  • Grey Primer
  • Red Primer

Click the images for a larger view.

Click Here to download more details from our library.

Preview Description PDF / DWG Download
